R&M 6 Core Armoured Multi Mode Loose Tube Fiber Optic Cable in Bangladesh
R&M 6 Core Armoured Multi Mode Loose Tube Fiber Optic Cable
R&M 6 Core Armoured Multi-Mode Loose Tube Fiber Optic Cable is an outdoor cable for applications in harsh conditions. It contains a central gel-filled loose tube (PBT) of a diameter of 3.0±0.1 mm. The outer sheath is made of a 0.150 mm ECCS tape armor plus a 2.0mm HDPE sheath. It consists of one RIP cord and the Fiber is G50/125 multimode (MM). It has IEC 60794-1-2 E1; IEC 60794-1-2 E11; IEC 60794-1-2 E3; IEC 60794-1-2 F1; IEC 60794-1-2 E4; IEC 60794-1-2 E7; IEC 60794-1-2 E10 Standardization. This cable has a centralized Loose Tube with Glass yarn as a peripheral strength member. The Fiber classified OM3 with 6 fiber conductors. The Cable jacket material is HDPE and the Cable jacket is water-tight with additional ECCS tape protection. The overall Cable diameter is 9.5 ± 0.5 mm and this FO cable has a loose tube, gel-filled Conductor while the Fiber conductor diameter is G50 125µm. This Multimode (MM) Fiber has a Tensile strength of 800 N and its Crush resistance reading is 2000 N per square meter. The minimum bending radius of this cable is 20 X D and the Operation Temperature range is from -20° C up to +70° C. the cable has an overall Length of 2000±10% meter. It has Gel Field, Glass Yarn at the Outdoor cable casing to make it water-proof.
What is the price of R&M 6 Core Armoured Multi Mode Loose Tube Fiber Optic Cable Cables in Bangladesh?
Have question about R&M 6 Core Armoured Multi Mode Loose Tube Fiber Optic Cable? Get specific details about this product from expert.
R&M 6 Core Armoured Multi Mode Loose Tube Fiber Optic Cable review
R&M 6 Core Armoured Multi Mode Loose Tube Fiber Optic Cable price
What is R&M 6 Core Armoured Multi Mode Loose Tube Fiber Optic Cable and its function?
What is R&M 6 Core Armoured Multi Mode Loose Tube Fiber Optic Cable used for?
6 Core Armoured Multi Mode R&M Networking Accessories lowest price in bd
R&M Networking Accessories 6 Core Armoured Multi Mode price in jashore
R&M 6 Core Armoured Multi Mode Loose Tube Fiber Optic Cable
- Brand: R&M
- Product Code: 6 Core Armoured Multi Mode
- Availability: In Stock
-
৳0
