Asus ROG STRIX X670E-A Gaming WIFI DDR5 AM5 ATX Motherboard
- Brand: Asus
- Product Code: PRIME X670E-PRO WIFI-CSM
- Availability: Out of Stock
- Updated:
Specification
| BASIC INFORMATION | |
| Form Factor | ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) |
|---|---|
| Raid controller | AMD RAID Xpert Technology supports both NVMe RAID 0/1/10 and SATA RAID 0/1/10. |
| Supported CPU | AMD Socket AM5 for AMD Ryzen 7000 Series Desktop Processors |
| Chipset | AMD X670 |
| Audio | 5 x Audio jacks |
| BIOS | 256 Mb Flash ROM, UEFI AMI BIOS |
| Expansion Slots | |
| M.2 Socket | Supports 4 x M.2 slots |
| PCI | AMD Ryzen™ 7000 Series Desktop Processors -1 x PCIe 5.0 x16 slot AMD X670 Chipset -1 x PCIe 4.0 x16 slot (supports x4 mode) -1 x PCIe 4.0 x4 slots |
| Graphics Specifications | |
| Graphics | 1 x DisplayPort 1 x HDMI port |
| Memory Specifications | |
| Maximum Memory | 192GB |
| Slots | 4 DIMMs |
| Supported Memory | 8000+(OC)/ 7800(OC)/ 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200/ 5000/ 4800 ECC & Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports AMD Extended Profiles for Overclocking (EXPO™) OptiMem II |
| Type | DDR5 |
| PORTS, CONNECTORS & SLOTS | |
| Display Port (s) | 1 x DisplayPort |
| HDMI | 1x HDMI |
| Internal I/O Ports | Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x 4-pin AIO Pump header 4 x 4-pin Chassis Fan headers 1 x W_PUMP+ header Power related 1 x 24-pin Main Power connector 2 x 8-pin +12V Power connectors Storage related 4 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 2 connector (supports USB Type-C) 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 3 x USB 2.0 headers support additional 6 USB 2.0 ports Miscellaneous 2 x Addressable Gen 2 headers 1 x AURA RGB header 1 x Clear CMOS button 1 x COM Port header 1 x CPU Over Voltage jumper 1 x Front Panel Audio header (AAFP) 1 x Power button 1 x SPI TPM header (14-1pin) 1 x 20-3 pin System Panel header with Chassis intrude function 1 x Thermal Sensor header 1 x Thunderbolt™ header |
| LAN Port (s) | 1 x Realtek 2.5Gb Ethernet ASUS LANGuard |
| Supported Storage | Total supports 4 x M.2 slots and 4 x SATA 6Gb/s ports AMD Ryzen™ 7000 Series Desktop Processors M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode) M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) AMD X670 Chipset M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes) M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) 4 x SATA 6Gb/s ports |
| USB (s) | Rear USB (Total 10 ports) 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C) 4 x USB 3.2 Gen 2 ports (3 x Type-A + 1 x USB Type-C) 5 x USB 3.2 Gen 1 ports (4 x Type-A + 1 x USB Type-C) Front USB (Total 9 ports) 1 x USB 3.2 Gen 2 connector (supports USB Type-C) 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 3 x USB 2.0 headers support additional 6 USB 2.0 ports |
| Wireless Communication module | Wi-Fi 6E 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax) Supports 2.4/5/6GHz frequency band |
| Special | |
| Bundled Software | ASUS Exclusive Software Armoury Crate - AURA Sync - Fan Xpert 4 (with AI Cooling II) - Power Saving - Two-Way AI Noise Cancelation AI Suite 3 - Easy Optimization - TPU - DIGI+ VRM - Turbo app - PC Cleaner ASUS CPU-Z IT Management software supported - ASUS Control Center Express(ACCE) DTS:X Ultra MyAsus Norton Anti-virus software (Free Trial version) WinRAR UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode FlexKey |
| Special Feature | ASUS 5X PROTECTION III - DIGI+ VRM (- Digital power design with DrMOS) - ESD Guards - LANGuard - Overvoltage Protection - Safeslot Core+ - Stainless-Steel Back I/O ASUS Q-Design - M.2 Q-Latch - PCIe Slot Q-Release - Q-Connector - Q-DIMM - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) - Q-Slot ASUS Thermal Solution - M.2 heatsink - VRM heatsink design ASUS EZ DIY - BIOS FlashBack™ button - BIOS FlashBack™ LED - Clear CMOS button - ProCool - Pre-mounted I/O shield - SafeSlot - SafeDIMM AURA Sync - AURA RGB header - Addressable Gen 2 headers |
| WARRANTY | |
| Manufacturing Warranty | 3 Years |
Description
Asus ROG STRIX X670E-A Gaming WIFI DDR5 AM5 ATX Motherboard: Unleash the Power of Gaming
The Asus ROG STRIX X670E-A Gaming WIFI DDR5 AM5 ATX Motherboard is engineered to provide gamers and PC enthusiasts with the ultimate gaming experience. This motherboard is packed with cutting-edge features that cater to high-performance gaming, content creation, and multitasking. It supports the latest AMD AM5 processors and utilizes DDR5 memory for blazing-fast data transfer rates, ensuring that your system operates smoothly under heavy loads.
Product Overview
At the core of this motherboard is the advanced X670E chipset, which allows for remarkable connectivity and performance. It features PCIe 5.0 support, ensuring that you can take full advantage of the latest graphics cards and SSDs. With multiple M.2 slots for NVMe SSDs, you can expand your storage without compromising on speed. This motherboard also boasts robust power delivery systems and premium capacitors to ensure stability during intense gaming sessions.
Benefits and Use Cases
The Asus ROG STRIX X670E-A is perfect for gamers who demand the best from their hardware. With built-in WiFi 6E, you can enjoy lag-free online gaming and seamless streaming. The customizable RGB lighting allows for a personalized touch to your gaming setup, while the comprehensive cooling solutions ensure that your components remain at optimal temperatures. Whether you’re a competitive gamer, a content creator, or just someone who enjoys high-end computing, this motherboard provides the versatility and power necessary to excel in any scenario.
Why Customers Should Buy This Product
Investing in the Asus ROG STRIX X670E-A means investing in quality and performance. The motherboard comes with a competitive warranty and exceptional after-sales support, making it a reliable choice for long-term use. Additionally, with its strong community presence and compatibility with a wide range of components, you can easily find upgrades and enhancements tailored to your needs. Choose this motherboard to future-proof your gaming rig and enjoy the latest technological advancements.
