MSI MAG B760M MORTAR DDR5 12th Gen & 13th Gen mATX Motherboard
Key highlights
- Form Factor: mATX 243.84mmx243.84mm
- Graphics: Support HDMITM 2.1 with HDR, the maximum resolution of 4K 60Hz Support DP 1.4, the maximum resolution of 4K 60Hz
- Raid controller: Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
- Supported CPU: Supports 12th/13th Gen Intel Core Processors, Pentium Gold and Celeron Processors LGA 1700
- Slots: 4
Description
High-Performance mATX Motherboard for Gamers
Elevate Your Gaming Experience with the MSI MAG B760M MORTAR DDR5 Motherboard
The MSI MAG B760M MORTAR DDR5 is the pinnacle of mATX motherboard design, expertly crafted to support the latest 12th and 13th Generation Intel processors. Whether you're a gamer, content creator, or a casual user, this motherboard provides a robust foundation for building a high-performance system. Its advanced thermal design ensures optimal performance, while the DDR5 memory support allows for lightning-fast data transfer speeds, enhancing your overall user experience.
One of the standout features of the MSI MAG B760M MORTAR is its exceptional connectivity options. With multiple PCIe slots, including support for PCIe 4.0 and PCIe 5.0, you can expand your system with the latest graphics cards and storage solutions. The motherboard also includes USB 3.2 Gen 2 ports, providing rapid data transfer rates for all your peripherals.
In terms of build quality, the MSI MAG B760M is designed to last. It features military-grade components, ensuring durability and longevity. The motherboard is also equipped with MSI's exclusive Mystic Light technology, allowing you to customize RGB lighting effects to match your style.
Choosing the MSI MAG B760M MORTAR means investing in a future-proof solution for your computing needs. Its compatibility with the latest Intel processors and expansions means your system can grow with you. For gamers in Jashore, Bangladesh, this motherboard offers an unbeatable combination of performance and features that ensure you stay ahead of the competition. Whether you're looking to build a powerhouse gaming rig or a versatile workstation, the MSI MAG B760M MORTAR is the perfect choice.
Upgrade Your PC with MSI MAG B760M DDR5 Features
Specification
| BASIC INFORMATION | |
|---|---|
| Form Factor | mATX 243.84mmx243.84mm |
| Graphics | Support HDMITM 2.1 with HDR, the maximum resolution of 4K 60Hz Support DP 1.4, the maximum resolution of 4K 60Hz |
| Raid controller | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices |
| Supported CPU | Supports 12th/13th Gen Intel Core Processors, Pentium Gold and Celeron Processors LGA 1700 |
| Slots | 4 |
| Audio | 1x Front Audio (JAUD) |
| Type | DDR5 |
| Connectivity | |
| HDMI | 1x HDMI |
| Expansion Slots | |
| PCI | 2x PCI-E x16 slot Supports x16/x4 1x PCI-E x1 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) |
| Memory Specifications | |
| Supported Memory | Support 7000+(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz Max. overclocking frequency: • 1DPC 1R Max speed up to 7000+ MHz • 1DPC 2R Max speed up to 6600+ MHz • 2DPC 1R Max speed up to 6400+ MHz • 2DPC 2R Max speed up to 5600+ MHz Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports Intel Extreme Memory Profile (XMP) |
| PORTS, CONNECTORS & SLOTS | |
| Display Port (s) | 2x DisplayPort |
| Internal I/O Ports | 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x CPU Fan 1x Pump Fan 4x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x TBT connector (JTBT, supports RTD3) 1x Tuning Controller connector(JDASH) 2x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 4x USB 2.0 ports 2x USB 3.2 Gen1 Type A ports 1x USB 3.2 Gen2 Type C ports |
| LAN Port (s) | Realtek 2.5Gbps LAN |
| Supported Storage | 2x M.2 M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices 4x SATA 6G |
| TPM (Trusted Platform Module ) | 1x TPM pin header(Support TPM 2.0) |
| USB (s) | 4x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 3.2 Gen1 Type A (Front) 3x USB 3.2 Gen2 Type A (Rear) 1x USB 3.2 Gen2 Type C (Front) 1x USB 3.2 Gen2x2 Type C (Rear |
| WARRANTY | |
| Manufacturing Warranty | 3 years |
