MSI MAG B760M MORTAR WIFI DDR5 12th Gen & 13th Gen mATX Motherboard
Key highlights
- Form Factor: mATX 243.84mmx243.84mm
- Graphics: Support HDMITM 2.1 with HDR, the maximum resolution of 4K 60Hz Support DP 1.4, the maximum resolution of 4K 60Hz
- Raid controller: Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
- Supported CPU: Supports 12th/13th Gen Intel Core Processors, Pentium Gold and Celeron Processors LGA 1700
- Chipset: INTEL B760
Description
Enhance Your PC with MSI MAG B760M Motherboard
Unleash the Power of Your Build with MSI MAG B760M MORTAR WIFI DDR5 Motherboard
The MSI MAG B760M MORTAR WIFI DDR5 is a meticulously engineered micro ATX motherboard designed to cater to the high demands of modern computing. Supporting Intel's 12th and 13th Gen processors, this motherboard stands out as an exceptional choice for gamers, content creators, and tech enthusiasts alike. With its robust construction and cutting-edge features, it promises to deliver unparalleled performance and reliability for both everyday tasks and intensive workloads.
Exceptional Connectivity: One of the standout features of the MAG B760M MORTAR is its comprehensive connectivity options. Equipped with Wi-Fi 6E technology, users can enjoy faster and more stable internet connections, crucial for online gaming and streaming. Additionally, the motherboard includes a variety of USB ports, including USB 3.2 Gen 2 Type-C, enabling quick data transfers and easy connectivity with external devices.
Superior Performance: Built to harness the full potential of DDR5 memory, this motherboard supports up to 128GB of RAM. The enhanced memory bandwidth and speed significantly improve multitasking and application loading times. This performance enhancement makes it ideal for video editing, 3D rendering, and gaming, allowing users to experience smooth and lag-free performance.
Enhanced Cooling Solutions: The MAG B760M MORTAR comes equipped with advanced thermal solutions, including extended heatsinks and multiple fan headers. This ensures optimal thermal performance, maintaining system stability even during high-demand situations. Gamers and heavy users will appreciate the peace of mind that comes with knowing their system is running cool and efficiently.
Versatile Expansion Options: This motherboard features multiple PCIe slots, enabling users to add additional graphics cards, storage devices, and other expansion cards as their needs evolve. Whether you're looking to build a gaming rig or a workstation, the MAG B760M MORTAR provides the flexibility to grow with you.
Why Choose the MSI MAG B760M MORTAR WIFI?: Customers in Bangladesh can greatly benefit from this product due to its availability of local support and warranty services. With its competitive pricing and advanced features, this motherboard is an excellent investment for anyone looking to build a high-performance PC. Don't settle for less; elevate your computing experience with the MSI MAG B760M MORTAR WIFI DDR5 motherboard.
Best DDR5 mATX Motherboard for Gamers in Bangladesh
Specification
| BASIC INFORMATION | |
|---|---|
| Form Factor | mATX 243.84mmx243.84mm |
| Graphics | Support HDMITM 2.1 with HDR, the maximum resolution of 4K 60Hz Support DP 1.4, the maximum resolution of 4K 60Hz |
| Raid controller | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices |
| Supported CPU | Supports 12th/13th Gen Intel Core Processors, Pentium Gold and Celeron Processors LGA 1700 |
| Chipset | INTEL B760 |
| Slots | 4 |
| Audio | 1x Front Audio (JAUD) |
| Type | DDR5 |
| Connectivity | |
| PCI-E | 2x PCI-E x16 slot Supports x16/x4 1x PCI-E x1 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) |
| Memory Specifications | |
| Maximum Memory | 192GB |
| Supported Memory | Support 7000+(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz Max. overclocking frequency: • 1DPC 1R Max speed up to 7000+ MHz • 1DPC 2R Max speed up to 6600+ MHz • 2DPC 1R Max speed up to 6400+ MHz • 2DPC 2R Max speed up to 5600+ MHz Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports Intel Extreme Memory Profile (XMP) |
| PORTS, CONNECTORS & SLOTS | |
| HDMI | 1x HDMI |
| Internal I/O Ports | 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x CPU Fan 1x Pump Fan 4x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x TBT connector (JTBT, supports RTD3) 1x Tuning Controller connector(JDASH) 2x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 4x USB 2.0 ports 2x USB 3.2 Gen1 Type A ports 1x USB 3.2 Gen2 Type C ports |
| LAN Port (s) | Realtek 2.5Gbps LAN |
| Supported Storage | 2x M.2 M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices 4x SATA 6G |
| TPM (Trusted Platform Module ) | 1x TPM pin header(Support TPM 2.0) |
| USB (s) | 4x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 3.2 Gen1 Type A (Front) 3x USB 3.2 Gen2 Type A (Rear) 1x USB 3.2 Gen2 Type C (Front) 1x USB 3.2 Gen2x2 Type C (Rear) |
| Wireless Communication module | Intel Wi-Fi 6E The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz (160MHz) up to 2.4Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax Supports Bluetooth 5.3, FIPS, FISMA |
| WARRANTY | |
| Manufacturing Warranty | 3 years |
