Key highlights
- Form Factor: mATX 220mmx243.84mm
- Raid controller: Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
- Supported CPU: Supports 14th/13th/12th Gen Intel Core Processors, Pentium Gold and Celeron Processors LGA 1700
- Chipset: INTEL B760
- Audio: Realtek ALC897 Codec 7.1-Channel High-Definition Audio
Description
Affordable MSI PRO B760M-G Motherboard in Jashore
Unlock Your Potential with the MSI PRO B760M-G mATX Motherboard
The MSI PRO B760M-G mATX Motherboard is designed for professionals and enthusiasts alike, providing a perfect blend of performance, reliability, and advanced features. Built to support Intel's latest 13th and 12th Gen processors, this motherboard is equipped with the LGA 1700 socket, allowing you to unleash the full potential of your CPU. With support for DDR4 memory up to 128GB, this board ensures that you can run multiple applications seamlessly, making it ideal for multitasking, content creation, and even gaming.
Exceptional Connectivity is another cornerstone of the MSI PRO B760M-G. With multiple USB ports, including USB 3.2 Gen 1 Type-A and Type-C, as well as HDMI and DisplayPort outputs for high-definition displays, you can connect all your peripherals without a hitch. The integrated Intel Wi-Fi 6 and Bluetooth 5.2 technology also provide fast wireless connectivity, making it easier to connect to the internet and other devices.
In terms of expandability, this motherboard features PCIe 4.0 slots, ensuring that you can upgrade your graphics card or add additional hardware when needed. The M.2 slots support NVMe SSDs, allowing for lightning-fast load times and data transfer speeds that can significantly enhance your computing experience.
One of the major benefits of the MSI PRO B760M-G is its robust build quality. The motherboard features high-quality components and a sturdy PCB design, ensuring long-lasting durability. Additionally, the Thermal Solution technology keeps the motherboard cool, even during intense gaming or heavy workloads. This attention to thermal management not only prolongs the lifespan of the motherboard but also enhances overall system stability.
Use Cases: Whether you are a gamer seeking high performance, a professional editor requiring reliability, or a casual user wanting a dependable system, the MSI PRO B760M-G caters to a wide range of users. Its features enable efficient multitasking, high-resolution gaming, and smooth operation of demanding applications.
Ultimately, customers should consider the MSI PRO B760M-G mATX Motherboard for its versatile features, exceptional performance, and reliability. The combination of advanced technology, comprehensive connectivity options, and robust build quality makes it a standout choice in the market.
Upgrade Your PC with MSI PRO B760M-G mATX
Specification
| BASIC INFORMATION | |
|---|---|
| Form Factor | mATX 220mmx243.84mm |
| Raid controller | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices |
| Supported CPU | Supports 14th/13th/12th Gen Intel Core Processors, Pentium Gold and Celeron Processors LGA 1700 |
| Chipset | INTEL B760 |
| Audio | Realtek ALC897 Codec 7.1-Channel High-Definition Audio |
| Connectivity | |
| VGA | 1x VGA |
| Expansion Slots | |
| PCI | 1x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 Gen PCIe 4.0 supports up to (From CPU) PCI_E2 Gen PCIe 4.0 supports up to (From Chipset) |
| Graphics Specifications | |
| Graphics | 1x HDMI Support HDMI™ 2.1 with HDR, maximum resolution of 4K 60Hz* 1x DisplayPort Support DP 1.4, maximum resolution of 4K 60Hz* 1x VGA Support VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz |
| Memory Specifications | |
| Maximum Memory | 96GB |
| Slots | 2 |
| Type | DDR5 |
| PORTS, CONNECTORS & SLOTS | |
| Display Port (s) | 1x DisplayPort |
| HDMI | 1x HDMI |
| Internal I/O Ports | 1x Power Connector(ATX_PWR) 1x Power Connector(CPU_PWR) 1x CPU Fan 2x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 2x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 4x USB 2.0 ports 2x USB 3.2 Gen1 Type A ports |
| LAN Port (s) | Realtek RTL8125B 2.5Gbps LAN |
| Supported Storage | 2x M.2 M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices 4x SATA 6G |
| TPM (Trusted Platform Module ) | 1x TPM pin header(Support TPM 2.0) |
| USB (s) | 2x USB 2.0 (Rear) 4x USB 2.0 (Front) 4x USB 3.2 Gen1 Type A (Rear) 2x USB 3.2 Gen1 Type A (Front) |
| Special | |
| Special Feature | 4x EZ Debug LED |
| WARRANTY | |
| Manufacturing Warranty | 3 years |
