MSI PRO B760M-P DDR5 mATX Motherboard
৳14,600
৳15,700
Key highlights
- Form Factor: mATX 243.84mmx243.84mm
- Raid controller: Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
- Supported CPU: Supports 14th/13th/12th Gen Intel Core Processors, Pentium Gold and Celeron Processors LGA 1700
- Chipset: INTEL B760
- Audio: Audio Connectors
Description
High-Performance MSI Motherboard for Gamers
Unleash Your Computing Potential with MSI PRO B760M-P DDR5 mATX Motherboard
The MSI PRO B760M-P DDR5 mATX Motherboard is designed for professionals and gamers who demand high performance, reliability, and advanced features in their computing systems. This motherboard is built on the latest Intel B760 chipset, supporting the latest 12th and 13th Gen Intel Core processors. With its compact micro ATX form factor, it provides exceptional versatility for various builds, making it an ideal choice for both home office setups and high-performance gaming rigs.
Key Features and Benefits:
- High-Speed DDR5 Memory Support: With support for up to 128GB of DDR5 RAM, the MSI PRO B760M-P allows for lightning-fast data transfer speeds, enhancing overall system performance.
- Advanced Cooling Solutions: Equipped with multiple fan headers and an extended heatsink design, this motherboard ensures optimal thermal performance, allowing you to push your system to its limits without overheating.
- Robust Connectivity Options: Featuring USB 3.2 Gen 2 Type-C ports, HDMI, and DisplayPort outputs, this motherboard provides extensive connectivity options for modern peripherals and displays, ensuring you stay connected no matter your setup.
- Durable Build Quality: MSI’s commitment to quality is evident in the PRO B760M-P’s construction, featuring military-grade components designed to withstand the rigors of daily use, ensuring longevity and reliability.
Use Cases: Whether you are a content creator needing robust multitasking capabilities or a gamer looking for a responsive and powerful platform, the MSI PRO B760M-P meets diverse computing needs. It’s perfect for assembling a high-performance workstation, a gaming setup, or even a home server. This motherboard is tailored for those who value performance, durability, and extensive features in their computing experience.
Why Choose MSI PRO B760M-P? In a competitive market, the MSI PRO B760M-P stands out due to its comprehensive feature set, robust build quality, and impressive performance metrics. Investing in this motherboard means investing in a future-proof solution that will adapt to your evolving computing needs. Additionally, with local availability in Jashore, Bangladesh, you can easily access support and service, ensuring peace of mind with every purchase.
Upgrade Your PC with MSI PRO B760M-P DDR5
Specification
| BASIC INFORMATION | |
|---|---|
| Form Factor | mATX 243.84mmx243.84mm |
| Raid controller | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices |
| Supported CPU | Supports 14th/13th/12th Gen Intel Core Processors, Pentium Gold and Celeron Processors LGA 1700 |
| Chipset | INTEL B760 |
| Audio | Audio Connectors |
| Connectivity | |
| VGA | 1x VGA |
| Graphics Specifications | |
| Graphics | 1x HDMI Support HDMI 1.4, maximum resolution of 4K 30Hz* 1x DisplayPort Support DP 1.4, maximum resolution of 4K 60Hz* 1x VGA Support VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz |
| Memory Specifications | |
| Maximum Memory | 192GB |
| Slots | 4 |
| Supported Memory | Memory Support DDR5 6800+(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz Max. overclocking frequency: • 1DPC 1R Max speed up to 6800+ MHz • 1DPC 2R Max speed up to 6400+ MHz • 2DPC 1R Max speed up to 6000+ MHz • 2DPC 2R Max speed up to 5600+ MHz Supports Intel XMP 3.0 OC Supports Dual-Controller Dual-Channel mode Supports non-ECC, un-buffered memory |
| Type | DDR5 |
| PORTS, CONNECTORS & SLOTS | |
| Display Port (s) | 1x DisplayPort |
| HDMI | 1x HDMI |
| Internal I/O Ports | 1x Power Connector(ATX_PWR) 1x Power Connector(CPU_PWR) 1x CPU Fan 2x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Printer Port (JLPT) 1x Com Port (JCOM) 1x RGB LED connector(JRGB) 4x USB 2.0 ports 2x USB 3.2 Gen1 Type A ports |
| LAN Port (s) | Realtek RTL8111H Gigabit LAN |
| Supported Storage | 2x M.2 M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices 4x SATA 6G |
| TPM (Trusted Platform Module ) | 1x TPM pin header(Support TPM 2.0) |
| USB (s) | 4x USB 2.0 (Rear) 4x USB 2.0 (Front) 1x USB 3.2 Gen1 Type A (Rear) 2x USB 3.2 Gen1 Type A (Front) 1x USB 3.2 Gen2 Type C (Rear) |
| Special | |
| Special Feature | 4x EZ Debug LED |
| WARRANTY | |
| Manufacturing Warranty | 3 years |
