ASRock H570 Steel Legend 10th and 11th Gen ATX Motherboard (No Warranty)
Key highlights
- Form Factor: ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm
- Raid controller: - Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices - Supports RAID 0 and RAID 1 for M.2 NVMe storage devices* *RAID function for PCIe mode SSD in M2_1 is only available with Intel® SSD installed.
- Chipset: Intel H570
- Audio: HD Audio Jacks: Line in / Front Speaker / Microphone
- BIOS: - 128Mb AMI UEFI Legal BIOS with multilingual GUI support - ACPI 6.0 Compliant wake up events - SMBIOS 2.7 Support - CPU Core/Cache, CPU GT, DRAM, VCCIO, VCCSA, VCCST, VCCIN AUX, VPPM Voltage Multi-adjustment
Description
High-Performance ATX Motherboard for Gamers & Professionals
ASRock H570 Steel Legend: A Robust Motherboard for Gaming and Productivity
The ASRock H570 Steel Legend is an exceptional ATX motherboard designed to support both 10th and 11th generation Intel processors. Built with high-quality components and a unique aesthetic that features a striking steel design, this motherboard is not only visually appealing but also highly functional. It is perfect for gamers, content creators, and professionals who demand the best performance from their systems. The H570 Steel Legend incorporates advanced technology, making it a reliable choice for any user.
Unmatched Performance: Equipped with the Intel H570 chipset, this motherboard supports PCIe 4.0 for faster data transfer speeds, allowing users to take full advantage of the latest GPUs and NVMe SSDs. With its dual-channel DDR4 memory support, you can achieve speeds of up to 3200MHz, enhancing your system's multitasking capabilities. This ensures a seamless experience whether you are gaming, streaming, or working on intensive tasks.
Comprehensive Connectivity Options: The ASRock H570 Steel Legend offers a plethora of connectivity options, including multiple USB 3.2 Gen 2 ports, HDMI, and DisplayPort outputs, as well as a 2.5GbE LAN port for lightning-fast network speeds. This extensive connectivity ensures that you can connect all your peripherals, from high-resolution monitors to external storage devices, without any hassle.
Durability and Build Quality: ASRock has designed the H570 Steel Legend with durability in mind. The motherboard features a reinforced steel back panel, ensuring it can withstand the rigors of daily use. Additionally, it comes with premium capacitors and a robust power delivery system, which helps maintain stability during intense gaming sessions or heavy workloads.
Why Choose the ASRock H570 Steel Legend?: This motherboard stands out in the crowded market due to its combination of performance, durability, and aesthetic appeal. Whether you are building a high-end gaming rig or a powerful workstation, the H570 Steel Legend provides the versatility and reliability you need. The absence of a warranty in this listing makes it a budget-friendly option for those who are comfortable with DIY builds and troubleshooting.
In conclusion, the ASRock H570 Steel Legend is an excellent choice for anyone looking to build a powerful and reliable PC. With its impressive features and robust build quality, it caters to both gamers and professionals. By choosing this motherboard from Unix Network in Jashore, Bangladesh, you are investing in a product that delivers exceptional performance and value for money.
Upgrade Your PC with ASRock H570 Steel Legend Features
Specification
| BASIC INFORMATION | |
|---|---|
| Form Factor | ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm |
| Raid controller | - Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices - Supports RAID 0 and RAID 1 for M.2 NVMe storage devices* *RAID function for PCIe mode SSD in M2_1 is only available with Intel® SSD installed. |
| Chipset | Intel H570 |
| Audio | HD Audio Jacks: Line in / Front Speaker / Microphone |
| BIOS | - 128Mb AMI UEFI Legal BIOS with multilingual GUI support - ACPI 6.0 Compliant wake up events - SMBIOS 2.7 Support - CPU Core/Cache, CPU GT, DRAM, VCCIO, VCCSA, VCCST, VCCIN AUX, VPPM Voltage Multi-adjustment |
| Expansion Slots | |
| PCI | 11th Gen Intel Core Processors - 2 x PCI Express x16 Slots (PCIE1/PCIE3: single at Gen4x16 (PCIE1); dual at Gen4x16 (PCIE1) / Gen3x4 (PCIE3))* 10th Gen Intel Core Processors - 2 x PCI Express x16 Slots (PCIE1/PCIE3: single at Gen3x16 (PCIE1); dual at Gen3x16 (PCIE1) / Gen3x4 (PCIE3))* - 3 x PCI Express 3.0 x1 Slots - Supports AMD Quad CrossFireX and CrossFireX - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel® CNVi (Integrated WiFi/BT) |
| Graphics Specifications | |
| Graphics | - 11th Gen Intel Core Processors support Intel Xe Graphics Architecture (Gen 12). 10th Gen Intel Core Processors support Gen 9 Graphics - Dual graphics output: support HDMI and DisplayPort 1.4 ports by independent display controllers - Supports HDMI 2.0 with max. resolution up to 4K x 2K (4096x2160) @ 60Hz with 11th Gen Intel Core Processors - Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) @ 30Hz with 10th Gen Intel Core Processors - Supports DisplayPort 1.4 with max. resolution up to 4K x 2K (4096x2304) @ 60Hz - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.0 Port (Compliant HDMI monitor is required) - Supports HDCP 2.2 with DisplayPort and HDMI Ports (HDCP 2.3 ready with 11th Gen Intel® Core™ Processors) |
| Memory Specifications | |
| Maximum Memory | 128GB |
| Slots | 4 x DIMM Slots |
| Supported Memory | - 11th Gen Intel Core Processors support DDR4 non-ECC, un-buffered memory up to 4800+(OC)* - 10th Gen Intel Core Processors support DDR4 non-ECC, un-buffered memory up to 4666+(OC)* - Supports ECC UDIMM memory modules (operate in non-ECC mode) - Supports Intel Extreme Memory Profile (XMP) 2.0 |
| Type | DDR4 |
| PORTS, CONNECTORS & SLOTS | |
| Display Port (s) | 1 x DisplayPort 1.4 |
| HDMI | 1 x HDMI Port |
| Internal I/O Ports | - 1 x Power LED and Speaker Header - 2 x RGB LED Headers* - 2 x Addressable LED Headers** - 1 x CPU Fan Connector (4-pin)*** - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)**** - 4 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)***** - 1 x 24 pin ATX Power Connector - 1 x 8 pin 12V Power Connector (Hi-Density Power Connector) - 1 x 4 pin 12V Power Connector (Hi-Density Power Connector) - 1 x Front Panel Audio Connector - 1 x Thunderbolt™ AIC Connector (5-pin) (Supports ASRock Thunderbolt™ 4 AIC Card) - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) - 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) (ASMedia ASM1074 hub) (Supports ESD Protection) - 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s) (Supports ESD Protection) |
| LAN Port (s) | 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) |
| Supported Storage | - 6 x SATA3 6.0 Gb/s Connectors* - 1 x Hyper M.2 Socket (M2_1), supports M Key type 2260/2280 M.2 PCI Express module up to Gen4x4 (64 Gb/s) (Socket M2_1 works with 11th Gen Intel® Core™ processors only)** - 1 x Ultra M.2 Socket (M2_2), supports M Key type 2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)** - 1 x Ultra M.2 Socket (M2_3), supports M Key type 2260/2280/22110 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s) |
| TPM (Trusted Platform Module ) | - 1 x SPI TPM Header |
| USB (s) | - 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) (ReDriver) (Supports ESD Protection) - 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) (ReDriver) (Supports ESD Protection) - 2 x USB 3.2 Gen1 Ports (Supports ESD Protection) - 2 x USB 2.0 Ports (Supports ESD Protection) |
| WARRANTY | |
| Manufacturing Warranty | No Warranty |
