- Price: ৳13,900
- Stock: In Stock
- Brand: MSI
- Model: PRO B760M-G DDR4
- MPN: 32003
Key Features
- Slots: 2
- Type: DDR4
- VGA: 1x VGA
- HDMI: 1x HDMI
- Maximum Memory: 64GB
- View More Info
Payment Options
BASIC INFORMATION | |
Form Factor | mATX 220mmx243.84mm |
Raid controller | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices |
Supported CPU | Supports 14th/13th/12th Gen Intel Core Processors, Pentium Gold and Celeron Processors LGA 1700 |
Chipset | INTEL B760 |
Audio | Realtek ALC897 Codec 7.1-Channel High-Definition Audio |
Connectivity | |
VGA | 1x VGA |
Expansion Slots | |
PCI | 1x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 Gen PCIe 4.0 supports up to (From CPU) PCI_E2 Gen PCIe 4.0 supports up to (From Chipset) |
Graphics Specifications | |
Graphics | 1x HDMI Support HDMI 2.1 with HDR, maximum resolution of 4K 60Hz 1x DisplayPort Support DP 1.4, maximum resolution of 4K 60Hz* 1x VGA Support VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz |
Memory Specifications | |
Maximum Memory | 64GB |
Slots | 2 |
Supported Memory | Memory Support 4800(OC)/ 4600(OC)/ 4400(OC)/ 4266(OC)/ 4200(OC)/ 4000(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3200(JEDEC)/ 2933(JEDEC)/ 2666(JEDEC)/ 2400(JEDEC)/ 2133(JEDEC) Max. overclocking frequency: • 1DPC 1R Max speed up to 4800+ MHz • 1DPC 2R Max speed up to 4600+ MHz Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports Intel® Extreme Memory Profile (XMP) |
Type | DDR4 |
PORTS, CONNECTORS & SLOTS | |
Display Port (s) | 1x DisplayPort |
HDMI | 1x HDMI |
Internal I/O Ports | 1x Power Connector(ATX_PWR) 1x Power Connector(CPU_PWR) 1x CPU Fan 2x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 2x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 4x USB 2.0 ports 2x USB 3.2 Gen1 Type A ports |
LAN Port (s) | Realtek RTL8125B 2.5Gbps LAN |
Supported Storage | 2x M.2 M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices 4x SATA 6G |
TPM (Trusted Platform Module ) | 1x TPM pin header(Support TPM 2.0) |
USB (s) | 2x USB 2.0 (Rear) 4x USB 2.0 (Front) 4x USB 3.2 Gen1 Type A (Rear) 2x USB 3.2 Gen1 Type A (Front) |
Special | |
Special Feature | 4x EZ Debug LED |
WARRANTY | |
Manufacturing Warranty | 3 years |
MSI PRO B760M-G DDR4 mATX Motherboard
The MSI PRO B760M-G DDR4 mATX Motherboard is a high-performance motherboard that supports a broad selection of Intel CPUs, making it an appealing option for both casual and professional users. This motherboard supports Intel Core 14th, 13th, and 12th Generation CPUs, as well as Pentium Gold and Celeron processors. It makes use of the LGA 1700 socket for a variety of CPU choices. The motherboard supports DDR4 memory, with a dual-channel configuration and a clock speed of 4800+MHz (when overclocked). This guarantees that multitasking and data management go smoothly. The Core Boost technology, with its superior architecture and digital power design, assures that the motherboard can handle more CPU cores, leading to higher overall performance. This is particularly useful for demanding applications. Memory Boost technology is used to transmit clean and reliable data signals, guaranteeing excellent performance, stability, and compatibility with the memory modules installed. PCIe 4.0 compatibility is included, as well as Lightning Gen4 x4 M.2 slots with M.2 Shield Frozr. This implies you may use high-speed storage devices and other PCIe peripherals to achieve lightning-fast data transfer and loading times. The addition of a 2.5 Gigabit LAN connector upgrades the network solution for professional and multimedia applications. This assures a safe, reliable, and fast network connection, lowering latency and enhancing streaming performance while online gaming. The motherboard has Audio Boost technology, which provides studio-level sound quality for an immersive gaming experience. This function is especially useful for gamers who value crystal-clear audio during gaming sessions. Steel Armor is included on the motherboard to protect VGA cards from bending and electromagnetic interference (EMI). This not only improves the performance and stability of your graphics card but also assures the motherboard's general robustness and endurance.
Looking for a reliable motherboard for your computer system? Look no further than the MSI PRO B760M-G DDR4 mATX Motherboard available at Computer Shop Unix Network in Jashore, Bangladesh. This motherboard is designed for professionals and gamers alike, with support for DDR4 memory and a microATX form factor for a compact build. With high-quality components and advanced features, the MSI PRO B760M-G ensures stability and performance for your computing needs. Upgrade your system today with this top-of-the-line motherboard from Computer Shop Unix Network.
The MSI PRO B760M-G DDR4 mATX Motherboard is a reliable and high-performance motherboard suitable for gaming enthusiasts and professional users alike. With its Micro ATX form factor, it is compatible with a wide range of computer cases, making it a versatile choice for building a powerful system.
Featuring DDR4 memory support, this motherboard can handle high-speed RAM modules for seamless multitasking and gaming performance. It also includes multiple expansion slots and connectors, including PCIe and SATA ports, for adding additional components such as graphics cards, storage drives, and peripherals.
Equipped with quality components and built-in cooling solutions, the MSI PRO B760M-G DDR4 mATX Motherboard ensures stable and efficient operation even under heavy workloads. Its comprehensive BIOS settings and software utilities allow users to customise and optimise system performance to suit their individual needs.
Overall, the MSI PRO B760M-G DDR4 mATX Motherboard is a reliable and feature-packed choice for those looking to build a high-performance computer system that can handle demanding tasks with ease.
