AFOX IH510D4-MA Intel Micro ATX Motherboard
- Brand:AFOX
- Product Code: IH510D4-MA
- Availability:In Stock
- Updated:
ক্যাম্পেইনের পণ্যে অন্য কোন অফার থাকলে সম্মানিত ক্রেতারা যেকোন একটি অফার উপভোগ করতে পারবেন।
Specification
| BASIC INFORMATION | |
| Form Factor | Micro-ATX |
|---|---|
| Graphics | Integrated |
| Operating System | Windows 10/11 |
| Supported CPU | Intel Core i3 / Core i5 / Core i7 / Core i9 Processors Supports Intel 10th /11th Generation (CPU up to 125 watts) |
| Chipset | Intel H510 |
| Memory | 64GB DDR4 |
| Slots | 2 |
| Audio | Realtek 662/887/897 on board, Supports 6-channel audio-out |
| BIOS | UEFI BIOS |
| External Features | |
| I/O Port | 1 x HDMI Port 1 x D-Sub (VGA) Port 1 x PS/2 Mouse Port 1 x PS/2 Keyboard Port 2 x USB 3.0 Ports 2 x USB 2.0 Ports 1 x RJ-45 LAN Port 3 x HD Audio Jacks (Line in / Front Speaker / Microphone) |
| PORTS, CONNECTORS & SLOTS | |
| LAN Port (s) | Realtek RTL8111 1000Mbps Ethernet on board Wake-On-LAN |
| WARRANTY | |
| Manufacturing Warranty | 3 year |
Description
AFOXIntel IH510D4-MA Intel H510 Micro-ATX Motherboard
The AFOXIntel IH510D4-MA is a Micro-ATX motherboard designed for office computers, home PCs, content creation, and budget gaming builds. Powered by the Intel H510 Express chipset, it supports compatible 10th and 11th Generation Intel processors through the LGA 1200 socket. With DDR4 memory support, an NVMe M.2 SSD slot, PCI Express graphics expansion, HDMI and VGA display outputs, and Gigabit LAN, this motherboard provides essential connectivity and storage features for everyday computing.
Intel LGA 1200 Socket with H510 Chipset
The AFOX IH510D4-MA features an Intel LGA 1200 socket and Intel H510 Express chipset. It supports compatible 10th Generation Intel Core processors based on Comet Lake and 11th Generation Intel Core processors based on Rocket Lake, along with supported Pentium and Celeron models. It is a practical choice for building or upgrading an Intel-based desktop PC for work, study, and entertainment.
NVMe M.2 SSD and SATA Storage Support
This AFOX motherboard features an M.2 SSD slot for compatible NVMe storage, helping improve system boot times, application loading, and file transfer performance. SATA 6Gb/s connectivity also allows users to install compatible SATA SSDs and traditional hard disk drives for additional storage capacity. Check the motherboard specifications to confirm supported M.2 interfaces and drive compatibility before purchasing an SSD.
Dual-Channel DDR4 Memory Support
The AFOXIntel IH510D4-MA includes two DDR4 DIMM slots for compatible desktop memory. It supports DDR4 memory speeds of up to 2933MHz or 3200MHz, depending on the installed processor and supported configuration. Dual-channel memory support can improve multitasking performance and help applications run smoothly during everyday office work, browsing, and content creation.
PCI Express Graphics Expansion with HDMI and VGA
The motherboard includes a PCI Express x16 slot for installing a compatible dedicated graphics card. This allows users to configure a desktop PC for improved graphics performance, gaming, and creative applications, depending on the selected GPU and the rest of the system. HDMI and VGA display outputs are available for compatible processors with integrated graphics, providing flexible monitor connectivity for home and office setups.
USB Connectivity, Gigabit LAN, and HD Audio
The AFOX IH510D4-MA provides USB 3.2 Gen 1 and USB 2.0 connectivity for compatible keyboards, mice, storage devices, printers, and other peripherals. Gigabit Ethernet LAN supports wired network connections, while the High Definition Audio chipset provides audio for video calls, online meetings, multimedia playback, and entertainment.
Why Choose the AFOXIntel IH510D4-MA Motherboard?
The AFOXIntel IH510D4-MA is suitable for users who need a compact motherboard with modern storage and connectivity options for a compatible Intel desktop build. Key features include an Intel H510 chipset, LGA 1200 socket, support for compatible 10th and 11th Generation Intel processors, two DDR4 DIMM slots, an M.2 SSD slot, SATA 6Gb/s connectivity, PCI Express x16 graphics expansion, HDMI and VGA outputs, USB connectivity, Gigabit LAN, and HD Audio. The product is listed with a 3-year official warranty, subject to the applicable warranty terms.
