MSI MAG B560M MORTAR 10th and 11th Gen Micro ATX Motherboard
৳17,100
Key highlights
- Form Factor: M-ATX
- Graphics: 1x HDMI 2.0b with HDR port, supports a maximum resolution of 4K 60Hz 1x DisplayPort 1.4 port, supports a maximum resolution of 4K 60Hz Supports 2-Way AMD CrossFire Technology
- Supported CPU: Supports 10th, 11th Gen Intel Core Processors, Pentium Gold and Celeron Processors for LGA1200 socket
- Chipset: Intel B560 Chipset
- Audio: 7.1-Channel High Definition Audio
Description
High-Performance Micro ATX Motherboard for Gamers
MSI MAG B560M MORTAR: Elevate Your Gaming Experience
The MSI MAG B560M MORTAR Micro ATX motherboard is a game-changer for gamers and PC builders alike. Designed to support both 10th and 11th Gen Intel processors, this motherboard combines cutting-edge technology with robust features to deliver exceptional performance. With its sleek design and advanced engineering, the MAG B560M MORTAR stands out in the crowded motherboard market.
Key Benefits:
- Enhanced Performance: With support for Intel Turbo Boost Technology, the MAG B560M MORTAR provides superior processing power, allowing for seamless multitasking and high-performance gaming.
- Advanced Cooling Solutions: The motherboard features multiple fan headers and MSI's proprietary thermal management solutions, ensuring that your system stays cool even during intense gaming sessions.
- Comprehensive Connectivity: Equipped with USB 3.2 Gen 2 ports, HDMI output, and PCIe 4.0 support, this motherboard provides the flexibility you need to connect all your peripherals and future-proof your setup.
- Easy Setup: The user-friendly BIOS interface and convenient installation features make building your PC a hassle-free experience, even for beginners.
Use Cases:
Whether you are a hardcore gamer, a content creator, or someone who simply wants a reliable workstation, the MSI MAG B560M MORTAR is designed to meet your needs. Its robust build quality ensures longevity, while its innovative features provide you with an edge in performance.
Why You Should Buy This Product:
Investing in the MSI MAG B560M MORTAR means investing in a motherboard that is built to last. Its high-quality components, impressive performance metrics, and extensive compatibility make it an ideal choice for anyone looking to build a powerful and efficient PC. Furthermore, with the growing popularity of eSports and gaming in Bangladesh, choosing a motherboard that enhances your gaming experience can make all the difference. Choose MSI MAG B560M MORTAR for a future-proof, high-performance motherboard that will empower your computing experience.
Upgrade Your Build with MSI MAG B560M MORTAR
Specification
| BASIC INFORMATION | |
|---|---|
| Form Factor | M-ATX |
| Graphics | 1x HDMI 2.0b with HDR port, supports a maximum resolution of 4K 60Hz 1x DisplayPort 1.4 port, supports a maximum resolution of 4K 60Hz Supports 2-Way AMD CrossFire Technology |
| Supported CPU | Supports 10th, 11th Gen Intel Core Processors, Pentium Gold and Celeron Processors for LGA1200 socket |
| Chipset | Intel B560 Chipset |
| Audio | 7.1-Channel High Definition Audio |
| Type | DDR4 |
| Connectivity | |
| HDMI | 1x HDMI 2.0b with HDR port, supports a maximum resolution of 4K 60Hz |
| Memory Specifications | |
| Maximum Memory | Up to 128GB |
| Supported Memory | Supports 1R 2133/ 2666/ 2933 MHz for 10th Gen Intel CPU (by JEDEC & POR) Supports 1R 2133/ 2666/ 2933/ 3200 MHz for 11th Gen Intel CPU (by JEDEC & POR) Max overclocking frequency: 1DPC 1R Max speed up to 5066+ MHz 1DPC 2R Max speed up to 4600+ MHz 2DPC 1R Max speed up to 4266+ MHz 2DPC 2R Max speed up to 4000+ MHz Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports Intel Extreme Memory Profile (XMP) |
| PORTS, CONNECTORS & SLOTS | |
| Display Port (s) | 1x DisplayPort 1.4 port, supports a maximum resolution of 4K 60Hz |
| Internal I/O Ports | 1x 24-pin ATX main power connector 1x 8-pin ATX 12V power connector 1x 4-pin ATX 12V power connector 6x SATA 6Gb/s connectors 2x M.2 slots (M-Key) 1x USB 3.2 Gen 2 10Gbps Type-C port 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports) 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1x 4-pin CPU fan connector 1x 4-pin water-pump fan connector 2x 4-pin system fan connectors 1x Front panel audio connector 2x System panel connectors 1x Chassis Intrusion connector 1x Clear CMOS jumper 1x Tuning Controller Connector 1x TBT connector (Supports RTD3) |
| USB (s) | Intel B560 Chipset: 1x USB3.2 Gen 2x2 20Gbps port (Type-C port on the back panel) 1x USB 3.2 Gen 2 10Gbps port (1 Type-C available through the internal connector) 2x USB 3.2 Gen 1 5Gbps ports are available through the internal USB 3.2 Gen 1 connector 4x USB 2.0 ports on the back panel USB Hubs ASM1074: 3x USB 3.2 Gen 1 5Gbps Type-A ports on the back panel Hub-GL850G: 4x USB 2.0 ports are available through the internal USB 2.0 connectors |
| WARRANTY | |
| Manufacturing Warranty | 03 years Warranty |
