GIGABYTE B660M GAMING X DDR5 Micro-ATX Motherboard in Bangladesh
- Brand: Gigabyte
- Product Code: B660M GAMING X DDR5
- Availability: Out Of Stock
Specification
| BASIC INFORMATION | |
| Form Factor | Micro ATX Form Factor; 24.4cm x 24.4cm |
| Raid controller | Support for RAID 0, RAID 1, RAID 5, and RAID 10 |
| Supported CPU | Support for 12th/ 13th/ 14th Generation Intel Core i9/ i7/ i5/ i3 processors and Intel Pentium processors/ Intel Celeron processors in the LGA1700 package L3 cache varies with CPU |
| Chipset | Intel B660 Express Chipset |
| Audio | 1 x front panel audio header |
| BIOS | 1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Expansion Slots | |
| M.2 Socket | 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2P_SB) 4 x SATA 6Gb/s connectors Support for RAID 0, RAID 1, RAID 5, and RAID 10 Intel Optane Memory Ready |
| PCI | 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) |
| Graphics Specifications | |
| Graphics | Integrated Graphics Processor-Intel HD Graphics support: 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz |
| Memory Specifications | |
| Maximum Memory | Up to 192 GB (48 GB single DIMM capacity) |
| Slots | 4 x DIMM |
| Supported Memory | Support for DDR5 5600(O.C.) / 5400(O.C.) / 5200(O.C.) /4800/4000 MHz memory modules 4 x DDR5 DIMM sockets supporting up to 192 GB (48 GB single DIMM capacity) of system memory Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules |
| Type | DDR5 |
| PORTS, CONNECTORS & SLOTS | |
| Display Port (s) | 1 x DisplayPort |
| HDMI | 1 x HDMI 2.1 port |
| Internal I/O Ports | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 3 x system fan headers 2 x addressable LED strip headers 2 x RGB LED strip headers 2 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C header, with USB 3.2 Gen 2 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x S/PDIF Out header 2 x Thunderbolt add-in card connectors 1 x serial port header 1 x reset button 1 x Q-Flash Plus button 1 x reset jumper 1 x Clear CMOS jumper Back Panel Connectors 3 x USB 3.2 Gen 1 ports 5 x USB 2.0/1.1 ports 1 x HDMI 2.1 port 1 x DisplayPort 1 x RJ-45 port 3 x audio jacks |
| LAN Port (s) | 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Supported Storage | CPU: 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) Chipset: 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2P_SB) 4 x SATA 6Gb/s connectors Support for RAID 0, RAID 1, RAID 5, and RAID 10 Intel Optane Memory Ready |
| TPM (Trusted Platform Module ) | 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) |
| USB (s) | Chipset: 1 x USB Type-C port with USB 3.2 Gen 2 support, available through the internal USB header 5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header) 1 x USB 2.0/1.1 port on the back panel Chipset+2 USB 2.0 Hubs: 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers) LAN Port (s) 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Special | |
| Bundled Software | Norton Internet Security (OEM version) LAN bandwidth management software |
| Special Feature | Support for APP Center @BIOS EasyTune RGB Fusion Smart Backup System Information Viewer Support for Q-Flash Plus Support for Q-Flash Support for Xpress Install |
| WARRANTY | |
| Manufacturing Warranty | 3 Years Warranty |
Description
GIGABYTE B660M GAMING X DDR5 Micro-ATX Motherboard Overview
The GIGABYTE B660M GAMING X DDR5 Micro-ATX Motherboard is designed for gamers and PC enthusiasts who demand high performance, cutting-edge technology, and reliability in their builds. This motherboard supports the latest Intel 12th generation processors, ensuring that users can experience the best performance available in the market. With its compact Micro-ATX form factor, it fits perfectly in smaller cases without compromising on features or capabilities.
Enhanced Performance: The B660M GAMING X features DDR5 memory support, allowing for higher speeds and greater bandwidth compared to previous generations. This results in faster load times and improved overall system responsiveness, making it an ideal choice for gaming, content creation, and multitasking.
Robust Gaming Features: Equipped with advanced gaming features, this motherboard includes multiple PCIe 4.0 slots for graphics and expansion cards, high-quality audio capacitors for immersive sound, and customizable RGB lighting to enhance your system's aesthetics. Gamers will appreciate the integrated features that help optimize the gaming experience.
Connectivity Options: The B660M GAMING X offers a wide array of connectivity options, including USB 3.2 Gen 2 Type-A and Type-C ports, allowing for rapid data transfer and compatibility with modern peripherals. The built-in Ethernet LAN ensures stable and fast internet connections, essential for online gaming.
Why Choose the GIGABYTE B660M GAMING X? This motherboard is ideal for gamers and PC builders who are seeking a balance of performance, aesthetics, and reliability. Its combination of features and specifications makes it a worthy investment for building a future-proof gaming rig or a powerful workstation. With GIGABYTE's commitment to quality and performance, customers can trust that they are making a sound decision by choosing this motherboard for their next build.
